Overview

14 AWG through 8 AWG Copper THHN Insulated Conductors. Full-Sized Aluminum Equipment Grounding/Bonding Conductor. UL Listed. 600 Volt. Rated VW1. Lightweight Aluminum Interlocked Armor is Part of Equipment Bonding/Grounding Path.

Application:

Type MC Cable - All Purpose is suitable for use as follows:
•Wherever standard AC or MC Cable is permitted.
•Branch circuit wiring in commercial, industrial, institutional, and multi-residential buildings.
•Fished or embedded in plaster.
•Concealed or exposed installations.
•Environmental air-handling spaces per NEC 300.22 (C).
•Places of Assembly per NEC 518.4 and theaters per NEC 520.5.
•Installation in cable tray and approved raceways.
•Under raised floors for information technology equipment conductors and cables per NEC 645.5(D) & 645.5(D)(2).
•Use UL Listed Type MCI-A connectors

Standards:

Type MC Cable meets or exceeds the following:
•UL 83 E511132
•UL 1569 E511436
•UL Online Product Guide Info - Metal-Clad Cable (www.ul.com )
•NFPA 70 (National Electrical Code), Article 330
•Federal Specification A-A59544 (formerly J-C-30B)
•FT4/IEEE 1202 (70,000 Btu/hr) Vertical Cable Tray Flame Test
•REACH/RoHS-2 (Chemical Limit) Compliant

Specifications

ROHS

Low Voltage

Flame Retardant

construction

Type MC Cable is constructed with solid soft-drawn copper Type THHN circuit conductors rated 90º C dry and a full-sized bare 8000 Series aluminum grounding/bonding conductor. This cable is available in sizes 14-8 AWG. The insulated conductors are cabled together and wrapped with a binder tape bearing the print legend. The bare aluminum grounding/bonding conductor is located outside the binding tape and has the same lay as the insulated conductors. Aluminum interlocking armor is snugly applied over the assembly. The aluminum armor and bare aluminum conductor are in intimate contact and together form the equipment ground path. To insure proper installation, refer to the installation instructions provided with every reel and coil.

parameter

MC Cable With Bare AL8000 Aluminum Alloy Ground

Conductor Size and Colors	Grounding/Bonding Conductor	Weight(LBS/1000')	Overall Diameter(Inch)
12-2 SOLID (BLACK/WHITE)	10 SOLID ALUMINUM	86	0.43
12-3 SOLID (BLACK/WHITE/RED)	10 SOLID ALUMINUM	111	0.447
